High-Efficiency Dongshan EPS Block Molding Machine

Efficient EPS Foam Block Forming Machines

The Dongshan DS series high-efficiency EPS foam block forming machines are designed for superior polystyrene block production. These machines offer precise size control, stable output, and batch production capabilities, making them ideal for various applications such as building insulation, packaging, and industrial products.

Model Specifications

• SPB2000LZ: Mould cavity size of 2040×1240×1030 mm and block size of 2000×1200×1000 mm.
• SPB3000LZ: Mould cavity size of 3060×1240×1030 mm and block size of 3000×1200×1000 mm.
• SPB4000LZ: Mould cavity size of 4080×1240×1030 mm and block size of 4000×1200×1000 mm.
• SPB6000LZ: Mould cavity size of 6080×1240×1030 mm and block size of 6000×1200×1000 mm.

Technical Specifications

• Steam Inlet: Ranging from 4 for SPB2000LZ to 8 for SPB6000LZ.
• Steam Consumption: 70–180 Kg/Cycle depending on the model.
• Compressed Air Inlet: 3 to 4 with a consumption of 1.5–4.5 M³/Cycle.
• Vacuum Inlet: 2 to 3 across models.
• Cooling Water Consumption: Varies from 0.6 to 1.4 Kg/Cycle.
• Energy Efficiency: Connected load ranges from 13/28 Kw to 16.5/28.5 Kw.

Designed for Performance and Consistency

Dongshan's EPS foam block forming machines are engineered to enhance production efficiency and consistency. They are user-friendly, reducing the complexity of manual operations and improving overall productivity.

Built to Last

• Durable Construction: Overall dimensions and robust weights ensure stability and longevity.
• Models: Weights range from 12,200 Kg for SPB2000LZ to 19,500 Kg for SPB6000LZ.
