High-Efficiency EPS Foam Cutting Machine

Technical Specifications of the SPC 4000 EPS Module Forming Machine

The SPC 4000 is an advanced EPS module forming machine engineered for precision and efficiency in EPS foam production. It supports diverse specifications to enhance production adaptability, making it the ideal choice for versatile manufacturing environments.

Basic Technical Data

• Suitable for Block Size: 4000mm x 1300mm x 1300mm
• Minimum Cutting Thickness: 10mm
• Cutting Speed: 0.5-1.5 meters per minute
• Maximum Wires in Horizontal Piece: 50
• Maximum Wires in Vertical Cutting Piece: 15
• Maximum Wires in Cross Cutting Piece: 15
• Hot Wire Specification: 0.4-0.8mm
• Connected Load: 24.8 Kw
• Machine Weight: 3500 Kg
• Contour Size: 18000mm x 3000mm x 2420mm

Advanced Features

• Automated Wire Setting: Horizontal wire setting is fully automatic.
• Manual Wire Setting: Vertical and cross-cutting wire setup are performed manually.
• Vibration Wire Cutting: Available for both horizontal and vertical cutting.

Conveyor and Output Capacity

• Belt Conveyor: Included for efficient movement and processing.
• Production Capacity: Capable of handling 7-10 blocks per hour for up to 4-meter-long blocks.

Product Highlights

The adjustable width EPS module forming machine enhances production flexibility and efficiency. By optimizing the hydraulic system and mold design, it ensures stable and uniform EPS block forming.

Benefits

• Adjustable Width: Rapid width adjustments to accommodate various product specifications effortlessly.
• Efficient Forming: Delivers consistent results with optimized design and technology.
• Durability and Reliability: Constructed from high-quality materials to ensure longevity and consistent performance.

Ideal Applications

• EPS Foam Board Production
• EPS Insulation Module Manufacturing
• Large EPS Molding Production Lines

Model Details

Model: SPC 4000 (Three Table)
