Smart EPP Molding Machine with Advanced PLC Controls

Advanced EPP Molding Solutions for Precision Industries

Our state-of-the-art EPP automatic molding equipment is engineered with premium materials, including aluminum, iron, and stainless steel components, integrated with a cutting-edge hydraulic control system and precision instrumentation. This ensures exceptional durability and production efficiency. Ideal for sectors with demanding standards for product complexity and precision, our machines are perfect for crafting high-quality packaging boxes, vegetable containers, fish crates, insulation boards, and more.

Technical Specifications

• Mold Frame Dimensions:
• EPP813: 1430X930 mm
• EPP1214: 1530X1330 mm
• EPP1318: 1930X1430 mm
• Rear Window Size:
• EPP813: 1350X850 mm
• EPP1214: 1450X1250 mm
• EPP1318: 1850X1350 mm
• Effective Molding Area:
• EPP813: 1200X700 mm
• EPP1214: 1300X1100 mm
• EPP1318: 1700X1200 mm
• Maximum Product Height: 400 mm

System Capacities

• Steam System: Pipeline DN 100-125, Working Pressure 5~8 Kg/cm²
• Air System: Pipeline DN 65-80, Working Pressure 4~5 Kg/cm²
• Cooling Water System: Pipeline DN 80-100, Working Pressure 3~4 Kg/cm²
• Sewage System: Vacuum Interface DN 100-125
• Hydraulic System:
• Oil Pump Motor: 7.5-11 Kw
• Maximum Clamping Force: 50-100 T

Machine Dimensions and Weight

• EPP813: 5200X2900X3100 mm, Weight 10 T
• EPP1214: 5500X3000X3700 mm, Weight 13 T
• EPP1318: 5800X3400X3800 mm, Weight 15 T

For businesses striving for excellence in complex and aesthetically demanding products, our EPP equipment provides unmatched precision and efficiency, making it the optimal choice for diverse manufacturing needs.
